Improved daisy chain design to connect 2 clusters of fans.
SL120 V2 fan frame thickness is 28mm to provide 10% improved airflow compared to V1.
Removable interlocking keys to provide better radiator clearance.
Start/stop fan RPM support for a quieter environment.
Smoother side lighting for a better aesthetic.
Only one cable is required for each fan cluster when using the provided new UNI HUB to control lighting effects via L-Connect 3.
Requires UNI HUB SLV2 Controller
| PRODUCT NAME | UNI FAN SL V2 120 | UNI FAN SL V2 140 | ||||||
|---|---|---|---|---|---|---|---|---|
| MODEL | UF-SL120V2-3B BLACK | UF-SL120V2-3W WHITE | UF-SL120V2-1B BLACK | UF-SL120V2-1W WHITE | UF-SL140V2-1B BLACK | UF-SL140V2-1W WHITE | ||
| COLOR | Black | White | Black | White | Black | White | ||
| NUMBER OF FANS | 3 | 3 | 1 | 1 | 1 | 1 | ||
| CONTROLLER | Yes | No | No | |||||
| CONNECTOR TYPE | 4 × 7-PIN (Power Cable) 2 × Extension Cable | 1 × 4-PIN PWM + 3-PIN SM Type 1 × ARGB MB Adaptor | 1 × 4-PIN PWM + 3-PIN SM Type 1 × ARGB MB Adaptor | |||||
| MATERIAL | PBT/PC/Aluminum) | |||||||
| RATED VOLTAGE | DC 12V (FAN) & 5V (LED) | |||||||
| FAN DIMENSION | 120 X 120 X 28 (mm) | 140 X 140 X 25 (mm) | ||||||
| FAN SPEED | 0, 250~2000 RPM | 0, 250~1600 RPM | ||||||
| MAX. AIR PRESSURE | 2.59 mmH2O (Maximum) | 2.09 mmH2O (Maximum) | ||||||
| MAX. AIRFLOW | 64.5 CFM (Maximum) | 77.6 CFM (Maximum) | ||||||
| ACOUSTIC NOISE | 29.2 dB(A) Max | 29 dB(A) Max | ||||||
| LOCKED CURRENT | 0(Automatic Protection) | |||||||
| BEARING TYPE | Fluid Dynamic Bearing (FDB) | |||||||
| OPERATE VOLTAGE | DC12V & 5V | |||||||
| START-UP VOLTAGE | ?5V | |||||||
| INPUT CURRENT | 0.17A | 0.11A | ||||||
| INPUT POWER | 2.04W | 1.32W | ||||||
| WARRANTY | 2 years | |||||||
2 Year
Manufacturers Warranty
