$159
Click & Collect
In stock at Mt Gravatt
Delivery
Avaliable for Fast Dispatch
Buy Now, Pay Later. T&Cs Apply
| Specification | Details |
|---|---|
| Width | 150 mm |
| Height | 86 mm |
| Depth | 150 mm |
| Specification | Details |
|---|---|
| Wattage | 1000 W |
| Form Factor | ATX |
| ATX Version | 3.1 |
| 80 PLUS Rating | Gold |
| Cybenetics Efficiency | Platinum |
| Cybenetics Noise | A+ |
| Modular | Fully modular |
| Capacitors | 105°C performance capacitors |
| Cable Type | Individually embossed with cable comb |
| Zero RPM Fan Mode | Yes |
| Cable Type | Length & Quantity |
|---|---|
| 24-pin ATX Power Cable | 600 mm (1) |
| 4+4-pin CPU Power Cable | 700 mm (1) |
| 8-pin CPU Power Cable | 700 mm (1) |
| 6+2-pin PCIe Power Cable | 650 mm (3) |
| 16-pin (12+4) 12V-2x6 PCIe Cable | 650 mm (1) (600W) |
| SATA Cables | 500 + 100 mm (8) |
| Peripherals Cable | 500 + 100 mm (3) |
| Region | Voltage & Current |
|---|---|
| Global | 100 – 240 Vac, 12A – 6A, 50Hz – 60Hz |
| South Korea | 200 – 240 Vac, 6A, 50Hz – 60Hz |
| Rail | Output |
|---|---|
| +3.3 V and +5 V | 20 A (120 W) |
| +12 V | 83.3 A (1000 W) |
| 5VSB | 3 A (15 W) |
| Total | 1000 W |
| Load | Efficiency @ 115 V |
|---|---|
| 10% | 87% |
| 20% | 92.22% |
| 50% | 92.18% |
| 100% | 89.1% |
| Specification | Details |
|---|---|
| Size | 135 mm |
| Type | PWM |
| Speed | 2,300 ± 10% RPM |
| Airflow | 103.36 CFM |
| Noise Level | 40.5 dBA |
| Bearing | Fluid dynamic bearing |
| Specification | Details |
|---|---|
| MTBF | 100,000 hours |
| Temperature | 0 – 50°C (Continuous Full Load) |
| Specification | Details |
|---|---|
| PF Correction | Active @ 0.99 |
| Protections | OVP, UVP, SCP, OTP, OPP, OCP |
| Specification | Details |
|---|---|
| Warranty | 7 years |
| Compliance Standard | ATX12V v3.1 / EPS12V v2.92 |
| Regulation & Certification | CE, UKCA, FCC, IC, BSMI, CB (IEC 62368-1 Ed. 3), RCM, KC |
| Model Number | PA-0G3BB-US / EU / UK / JP / AU |
| UPC | US: 810074849210 / EU: 810074849227 / UK: 810074849234 / JP: 810074849241 / AU: 810074849258 |
| EAN | US: 5056547208749 / EU: 5056547208756 / UK: 5056547208763 / JP: 5056547208770 / AU: 5056547208787 |
7 Year
Manufacturers Warranty
