Original price was: $1,469.$1,299Current price is: $1,299.
Click & Collect
Out of stock
Delivery
Out of stock
Buy Now, Pay Later. T&Cs Apply
| Item | Details |
|---|---|
| Dimensions | 442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
| Port Layout | 10 GbE RJ45: 10 (All PoE+++) (10G/5G/2.5G/1G/100M) 10G SFP+: 2 (10G/1G) |
| Max. PoE Output | Up to PoE+++ |
| Total PoE Availability | 400W |
| Redundancy | DC Power Backup |
| Layer 3 | ? |
| Form Factor | Rack mount (1U) |
| Etherlighting™ | ? |
| Item | Details |
|---|---|
| Switching Capacity | 240 Gbps |
| Total Non-Blocking Throughput | 120 Gbps |
| Forwarding Rate | 179 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 32,000 |
| L3 Table Size | ARP Entries: 12,000 IPv4 Routes: 12,000 |
| Packet Buffer Size | 2 MB |
| Access Lists | IPv4: 128 MAC: 128 |
| Feature | Supported |
|---|---|
| DHCP Server (Local Networks) | ? |
| DHCP Relay | ? |
| Inter-VLAN Routing (Local Networks) | ? |
| Static Routing (Local Networks) | ? |
| Feature | Supported |
|---|---|
| LACP Port Aggregation | ? |
| STP & RSTP | ? |
| QoS (DSCP) | ? |
| Pro AV Profiles | ? |
| Advanced IGMP Configuration | ? |
| IGMP Snooping | ? |
| 802.1X Control | ? |
| MAC-Based ACLs & Device Isolation | ? |
| DHCP Snooping & Guarding | ? |
| Egress Rate Limit | ? |
| Flow Control | ? |
| Storm Control | ? |
| Multicast & Broadcast Rate Limiting | ? |
| MAC Address Blocking | ? |
| IP-Based ACLs & Network Isolation | ? |
| MAC-Based Port Restriction | ? |
| Port Isolation | ? |
| Port Mirroring | ? |
| Jumbo Frames | ? |
| LLDP-MED | ? |
| Voice VLAN | ? |
| Loop Protection | ? |
| Item | Details |
|---|---|
| PoE Ports | PoE+++: 10 |
| Max. PoE Wattage per Port by PSE | PoE: 15.4W PoE+: 30W PoE++: 60W PoE+++: 90W |
| Max. Power Consumption | 65W (Excluding PoE) 520W (Including PoE) |
| Power Method | (1) Universal input, 100–240V AC, 50/60 Hz (1) USP RPS DC input |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 550W |
| Supported Voltage Range | 100–240V AC |
| Item | Details |
|---|---|
| Ethernet | AR |
| Weight | Without brackets: 4.6 kg (10.14 lb) With brackets: 4.7 kg (10.36 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400–1200 mm (15.7–47.2") |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ±30kV Contact: ±30kV |
| Ambient Operating Temperature | -5 to 40°C (23 to 104°F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| Interface | Supported |
|---|---|
| Ethernet | ? |
| SFP+ | ? |
| Indicator | Supported |
|---|---|
| RPS | ? |
| System | ? |
| Item | Details |
|---|---|
| NDAA Compliant | ? |
| Certifications | CE, FCC, IC |
| Item | Details |
|---|---|
| Application Requirements | UniFi Network Version 9.1.120 and later |
2 Year
Manufacturers Warranty
