This product is no longer avaliable.
See suggested alternative models below.
Intel Denverton-based Atom C3538 Quad-Core CPU
8GB DDR4-2133 SO-DIMM, 30% faster than DDR3
Dual Intel 10-Gigabit Ethernet ports, Supports up to 20 Gbps under Link Aggregation
Dual Realtek 2.5-Gigabit Ethernet ports, Supports up to 5 Gbps under Link Aggregation
Supports 8x 3″ SATA hard drives and SSDs
Dual M.2 NVMe SSD ports for fast caching
Supports an extra 144 TB with the AS6004U
Thumbscrews for easy M.2 SSD installation
Supports Wake on LAN and Wake on WAN
Efficient cooling design
Best in class three year warranty
Hardware Specifications |
||
|---|---|---|
CPU |
CPU Model | Intel ATOM C3538 |
| CPU Architecture | x64 64-bit | |
| CPU Frequency | Quad-Core 2.1GHz | |
Memory |
Memory | 8GB SO-DIMM DDR4 Compatibility |
| Memory Module Pre-installed | 8GB (1x 8GB) | |
| Total Memory Slots | 2 | |
| Memory Expandable up to | 64GB (2x 32GB) Installation Guide
|
|
| Flash Memory | 4GB eMMC | |
Storage |
Drive Bays | 10 |
| M.2 Drive Slots | 2 Installation Guide | |
| Compatible Drive Type Compatibility |
|
|
| M.2 PCIe Interface | PCIe 3.0 x2 | |
| Maximum Drive Bays with Expansion Unit | 18 | |
| Supports Hot Swappable Drives | ||
External Ports |
Expansion | 2x USB 3.2 Gen 1 |
| Network |
|
|
|
|
Multimedia Output | N/A |
Others |
System Fan | 2x 120mm |
| LCD Panel | ||
| Power Supply Unit / Adapter | 250W x1 | |
| Input Power Voltage | 100V to 240V AC | |
| Certification | FCC, CE, VCCI, BSMI, C-TICK | |
| Warranty | 3 Years | |
Operation |
Power Consumption | 76.8W (Operation); 41.1W (Disk Hibernation); |
| Noise Level | 22dB (HDD idle) | |
| Operation Temperature | 0°C~40°C (32°F~104°F) | |
| Storage Temperature | -20°C~70°C (-4°F~158°F) | |
| Humidity | 5% to 95% RH | |
Size and Weight |
Size | 215.5(H) x 293(W) x 230(D) mm |
| Weight | 6.4 (kg) / 14.1 (lb) Package Contents | |
3 Year
Manufacturers Warranty
