| CPU | Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors* Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0** * Refer to www.asus.com for CPU support list. ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. |
|---|---|
| Chipset | Intel® B760 Chipset |
| Memory | 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) OptiMem II * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics | 1 x DisplayPort** 1 x HDMI™ port*** ** Supports max. 4K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI™ 2.1. |
| Expansion Slots | Intel® Core™ Processors (14th & 13th & 12th Gen): - 1 x PCIe 5.0 x16 slot Intel® B760 Chipset: - 1 x PCIe 3.0 x16 slot (supports x4 mode) - 2 x PCIe 3.0 x1 slots * PCIEX16(G3) shares bandwidth with PCIEX1(G3)_1 and PCIEX1(G3)_2. |
| Storage | Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports* Intel® Core™ Processors: - M.2_1 slot (Key M), type 2242/2260/2280 (PCIe 4.0 x4) Intel® B760 Chipset: - M.2_2 slot (Key M), type 2242/2260/2280/22110 (PCIe 4.0 x4) - M.2_3 slot (Key M), type 2242/2260/2280 (PCIe 4.0 x4) - 4 x SATA 6Gb/s ports * Supports SATA RAID 0/1/5/10. |
| Ethernet | 1 x Realtek 2.5Gb Ethernet, TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6 (802.11 a/b/g/n/ac/ax), 2x2, Supports 2.4/5GHz Bluetooth® v5.2* |
| USB | Rear (6 ports): - 1 x USB 3.2 Gen 2x2 (Type-C®) - 1 x USB 3.2 Gen 2 (Type-A) - 3 x USB 3.2 Gen 1 (Type-A) - 1 x USB 2.0 (Type-A) Front (7 ports): - 1 x USB 3.2 Gen 2 connector (Type-C®) - 1 x USB 3.2 Gen 1 header (2 ports) - 2 x USB 2.0 headers (4 ports) |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports Jack-detection, Multi-streaming, Front Panel Jack-retasking - Up to 24-Bit/192 kHz playback Features: Audio Shielding, Rear optical S/PDIF out, Premium capacitors, Dedicated PCB layers, Audio cover |
| Back Panel I/O | 1 x USB 3.2 Gen 2x2 (Type-C®) 1 x USB 3.2 Gen 2 (Type-A) 3 x USB 3.2 Gen 1 (Type-A) 1 x USB 2.0 (Type-A) 1 x DisplayPort 1 x HDMI™ port 1 x Wi-Fi Module 1 x Realtek 2.5Gb Ethernet 5 x Audio jacks 1 x Optical S/PDIF out |
| Internal I/O | Cooling: 1 x CPU Fan, 1 x CPU OPT Fan, 1 x AIO Pump, 4 x Chassis Fan Power: 1 x 24-pin, 1 x 8-pin +12V, 1 x 4-pin +12V Storage: 3 x M.2 slots, 4 x SATA ports USB: 1 x USB 3.2 Gen 2 (Type-C®), 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports) Misc: 3 x Addressable Gen 2 headers, 1 x Aura RGB header, Clear CMOS, COM Port, Front Audio, System Panel, Thunderbolt™ header |
| Special Features | ASUS TUF Protection (DIGI+ VRM, ESD Guards, LANGuard, Overvoltage Protection, SafeSlot Core+, Stainless-Steel Back I/O) ASUS Q-Design (M.2 Q-Latch, Q-DIMM, Q-LED, Q-Slot) ASUS Thermal Solution (M.2 heatsink, VRM heatsink) ASUS EZ DIY (CPU Socket lever protector, ProCool, Pre-mounted I/O shield, SafeSlot Core+, SafeDIMM) Aura Sync (RGB header, Addressable Gen 2 headers) |
| Software Features | Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, Power Saving, AI Noise Cancellation) AI Suite 3 (DIGI+ VRM, PC Cleaner) TUF GAMING CPU-Z, DTS Audio Processing, MyASUS, Norton 360 for Gamers, WinRAR |
| UEFI BIOS | ASUS EZ DIY (CrashFree BIOS 3, EZ Flash 3, UEFI BIOS EZ Mode) |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | Cables: 2 x SATA cables Misc: Wi-Fi antenna, TUF Gaming sticker, 2 x M.2 Rubber Packages, M.2 SSD screw package Docs: TUF Certification card, User guide |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Form Factor | ATX, 12" x 9.6" (30.5 cm x 24.4 cm) |
3 Year
Manufacturers Warranty
