Platform

Desktop

Product Family

AMD Ryzen™ Processors

Product Line

AMD Ryzen™ 9 Desktop Processors

# of CPU Cores

12

# of Threads

24

Max. Boost Clock

Up to 5.6GHz

Base Clock

4.7GHz

L1 Cache

768KB

L2 Cache

12MB

L3 Cache

64MB

Default TDP

170W

Processor Technology for CPU Cores

TSMC 5nm FinFET

Unlocked for Overclocking AMD`s product warranty does not cover damages caused by overclocking, even when overclocking is enabled via AMD hardware and/or software. GD-26.

Yes

CPU Socket

AM5

Max. Operating Temperature (Tjmax)

95°C

Launch Date

9/27/2022

*OS Support

Windows 11 - 64-Bit Edition

Windows 10 - 64-Bit Edition

RHEL x86 64-Bit

Ubuntu x86 64-Bit

*Operating System (OS) support will vary by manufacturer.

Memory Channels

2

Max Memory Speed

1x1R

5200 MT/s

1x2R

5200 MT/s

2x1R

3600 MT/s

2x2R

3600 MT/s

Graphics Model

AMD Radeon™ Graphics

Graphics Core Count

2

Graphics Frequency

2200 MHz

GPU Base

400 MHz

Product ID Boxed

100-100000589WOF

Product ID Tray

100-000000589

Supported Technologies

AMD EXPO™ Technology

AMD Ryzen™ Technologies
