ASUS TUF Gaming Capture Box FHD120
Web ID: 39524
Offers passthrough video support of up to 4K at 60 Hz, 2K at 60 Hz, and Full HD at 120 Hz.
Delivers video streaming up to 120 fps in Full HD.
Two 3.5 mm jacks enable connection with a controller and headset for game console party mode.
Certified OBS Studio compatibility ensures optimal usage on a wide variety of streaming platforms.
An onboard scaler automatically syncs streaming and input resolution for streamlining setup.
ARGB lighting signals the devices real-time operating status.
ASUS Video Capture Console is a software dashboard that enables customization of lighting effects and full audio control from your gaming device.
ONLY WHILE STOCKS LAST!
Manufacturer Warranty: 1 Year
Manufacturer PN: TUF Gaming Capture Box-FHD120
Manufacturer Website
Model
TUF Gaming Capture Box-FHD120
Product Name
ASUS TUF Gaming Capture Box-FHD120
Interface
Input: HDMI 2.0
Output: HDMI2.0
UVC Output: USB 3.2 Gen1x1 Type-C©
Max.Video Input/Pass Through(Resolution)
4K60,2K60, 1080p120, 1080p60, 1080p30, 1080i, 720p60, 576p50,480p60
Video Input
4K60,2K60, 1080p120, 1080p60, 1080p30, 1080i, 720p60, 576p50,480p60
Video Output(Passthrough)
USB 3.2 Gen1x1 Type-C ©: Uncompressed
1080p120, 1080p60, 1080p30, 1080i, 720p60, 720p30,576p50,480p60
USB 2.0: Uncompressed
720p30,720p25
Max.Video Capture(Resolution)
USB 3.2 Gen1x1 Type-C ©: Uncompressed
1080p120, 1080p60, 1080p30, 1080i, 720p60, 720p30,576p50,480p60
USB 2.0: Uncompressed
720p30,720p25
Hardware Scaler
Down-scaling & Up to 1080p Up-scaling
Audio Input
Down-scaling & Up to 1080p Up-scaling
Audio Output(Passthrough)
Audio (Mic In / Audio Out) 3.5mm
Game Pad (Mic Out / Audio In) 3.5mm
Extra Ports(Console Party Chat)
Audio (Mic In / Audio Out) 3.5mm
Game Pad (Mic Out / Audio In) 3.5mm
LED Indicator
ARGB Customizable Lighting Effects
Video Resolution(Input)
ARGB Customizable Lighting Effects
Max Video Resolution(Passthrough)
11.5cm(W)x9cm(D)x2.1cm(H)
Dimension
11.5cm(W)x9cm(D)x2.1cm(H)
Max Video Resolution (Recording)
140 (g)
Audio Mix Input
PS4
PS4 Pro
PS5
Xbox One
Series X/S
Nintendo Switch
PC
MAC
Platform Support
PS4
PS4 Pro
PS5
Xbox One
Series X/S
Nintendo Switch
PC
MAC
In-Box Content
Quick Start Guide*1
HDMI 2.0 Cable*1
USB 3.2 Gen1x1 Type-C ® to Type A Cable*1
USB Type-A to Type-C ® Adapter*1
3.5 mm to 3.5mm Audio Cable*1
Game Console Compatibility
Quick Start Guide*1
HDMI 2.0 Cable*1
USB 3.2 Gen1x1 Type-C ® to Type A Cable*1
USB Type-A to Type-C ® Adapter*1
3.5 mm to 3.5mm Audio Cable*1
Indicator
*This product does not support viewing/ recording/ streaming of HDCP protected signals.
*You can download a newer firmware and ASUS Video Capture Console Software from Driver & Utility on ASUS official website.
* All specifications are subject to change without notice. Please check with your supplier for exact offers.
System Requirements(Desktop)
Intel® Core™ i5-6XXX or above
Recommended:Intel® Core™ i7-6XXX or above
AMD® Ryzen™ 5 1XXX or above
Recommended:AMD® RYZEN™ 7 1XXX or above
8GB or above (Dual-channel)
Recommended:16GB or above (Dual-channel)
*You have to set your memory on dual channel mode in your computer system.
NVIDIA® GeForce® GTX660 or above
Recommended:NVIDIA® GeForce® GTX 1060 or above
AMD® Radeon™ HD7870 or above
Recommended:AMD® Radeon™ RX570 or above
USB 2.0 or above ( USB 3.2 Gen1x1 recommended)
System Requirements(Laptop)
Intel® Core™ i7-4810MQ or above
Recommended:Intel® Core™ i7-7700HQ or above
AMD® Ryzen™ 5 3500U or above
Recommended: AMD® RYZEN™ 5 3550H or above
8GB or above (Dual-channel)
Recommended:16GB or above (Dual-channel)
*You have to set your memory on dual channel mode in your computer system.
NVIDIA® GeForce® GTX 870M or above
Recommended:NVIDIA® GeForce® GTX 1050 Ti or above
AMD® Radeon™ HD8970M or above
Recommended:AMD® Radeon™ RX570 or above
USB 2.0 or above ( USB 3.2 Gen1x1 recommended)
Dimension(W x D x H)
Intel® Core™ i5-6XXX or above
Recommended:Intel® Core™ i7-6XXX or above
AMD® Ryzen™ 5 1XXX or above
Recommended:AMD® RYZEN™ 7 1XXX or above
8GB or above (Dual-channel)
Recommended:16GB or above (Dual-channel)
*You have to set your memory on dual channel mode in your computer system.
NVIDIA® GeForce® GTX660 or above
Recommended:NVIDIA® GeForce® GTX 1060 or above
AMD® Radeon™ HD7870 or above
Recommended:AMD® Radeon™ RX570 or above
USB 2.0 or above ( USB 3.2 Gen1x1 recommended)
Weight
140 (g)
Intel® Core™ i7-4810MQ or above
Recommended:Intel® Core™ i7-7700HQ or above
AMD® Ryzen™ 5 3500U or above
Recommended: AMD® RYZEN™ 5 3550H or above
8GB or above (Dual-channel)
Recommended:16GB or above (Dual-channel)
*You have to set your memory on dual channel mode in your computer system.
NVIDIA® GeForce® GTX 870M or above
Recommended:NVIDIA® GeForce® GTX 1050 Ti or above
AMD® Radeon™ HD8970M or above
Recommended:AMD® Radeon™ RX570 or above
USB 2.0 or above ( USB 3.2 Gen1x1 recommended)
NOTE:
*This product does not support viewing/ recording/ streaming of HDCP protected signals.
*You can download a newer firmware and ASUS Video Capture Console Software from Driver & Utility on ASUS official website.
* All specifications are subject to change without notice. Please check with your supplier for exact offers.
